MIG welding is usually easier to learn than TIG welding, yet stick welding is the most complicated. Electrode manipulation and application are some of the most difficult parts of the stick welding technique. This text will expound on the constituent electrodes in use in performing stick welding on carbon steel, their advantages and disadvantages, giving you an idea of the most challenging ones to conduct.
What is the hardest welding rod to use?
When it comes to material qualities, the hardest welding rod you should use isn’t always the hardest. A welding rod’s degree of difficulty might vary depending on the coating, the properties of the arc, and the welding location.
The following are a few of the hardest welding rods to use:
1. E6010: This rod is best for welding in the flat position. This rod has a very stiff, penetrating arc hard to control especially for beginners.
2. E6011: E6011 similar to the 6011 Welding Rod has rather a vigorous ark that easily penetrates deeper but with difficulty in keeping it steady, it can be applied in all positions while being particularly tricky in vertical and overhead welding situations.
3. E7018: Alloy 7018 low-hydrogen rods are not the most difficult to work with, but special procedures are required to ensure that they contain low amounts of hydrogen. They need to be kept away from water and maybe baked if necessary before being employed.
4. Hardfacing rods: Face hardfacing rods, such as those manufactured by Ador Fontech, can be difficult to use because of their high alloy contents and thick coatings. The avoidance of cracking necessitates a consideration of the correct preheat and interpass temperatures.
Stick Welding Electrodes Comparison Chart
E6010: Digs Deep, Heats Up Quickly, and Welds Quickly
The E6010 stick welding electrode is one of the most difficult stick rods to manage; as such, it is generally the province of seasoned professionals who discourage new entrants from employing it. Still, beginners are at liberty to employ this rod though there are more suitable ones as we shall learn later.
The E6010 is often referred to as the favoured electrode for pipe welding among welders due to its ability for rapid welds with high-rate deposition. These electrodes are barbaric because they penetrate deeply into materials enabling even dirty or oxidized surfaces well. However, the area you plan on joining should be cleaned before the application of any welding process.
The burnt flux emits a lot of CO2; thus, protecting the molten metal just as in MIG welding when CO2 acts as a shield gas. However, on the other hand, arc voltage will be run on high by hydrogen. Weld penetration is achieved through increased CO2 and arc voltage, making E6010 the most penetrating electrode. This is what makes E6010 operate the way it does and the secret behind its power.
E6011 – Multi-Polarity Powerful Rod
The E6011 is somewhat similar to the E6010. It is more or less its younger sibling model. E6011 welding rods make use of potassium compound along with a cellulose mixture thus enabling the electrodes to operate on DCEP and AC power sources. Thus, the E6011 is considered a substitute for E6010 under circumstances where AC stick welders (commonly referred to as buzz boxes) are the only option.
One of the arc stabilisers is potassium. In essence, it permits the arc to remain lighted when welding with AC during the polarity transition.
These electrodes work better with alternating current, however, the penetration is a bit less. When the stinger switches polarities with a ground clamp, the polarity does so multiple times in a second; whenever this happens, the actual arcing stops amidst an electrode plus welded material and then begins afresh which leads to less penetration.
Furthermore, since E6010 is hard to run on many inverter-based SMAW welding machines, E6011 offers a good option as well. Though, while used with DCEP this electrode mirrors almost all the characteristics of E6010 it does not demand high power output just like this one. Nevertheless, Yeswelder has many cheap and quality stick welder models that handle E6010 natively. For example, Firstness MP200 from our company and YesWelder CT2050 usually do well when it comes to E6010 electrodes.
The Joyful Middle and the Best Friend for Beginners are E6012 and E6013.
The E6012 and E6013 are rutile electrodes, unlike the E6010 and E6011. They contain no cellulose in their flux. While E6012 has generally higher amounts of titanium dioxide, the same applies to sodium in its covering, such that during welding, a lot of CO2 comes from the flux leading to the formation of gas. When it comes to potassium, the E6013 mainly depends on titanium dioxide.
The E6012 works with DCEN polarity, and also supports AC; the difference is evident. DCEP is used to operate cellulosic electrodes (E6010 and E6011), while rutile electrodes (E6012 and E6013) run on DCEN, having shallower penetration. It is therefore impossible not to note that E6012 is ideal for welding thin materials and doing minor fixes.
E7018 – Low Hydrogen Electrode – Easy and Powerful
The E7018 electrodes are used by everyone, even enthusiasts. These rods are intended for expert, superior welding. However, they produce great welds and are reasonably simple to run. The E7018 is very versatile, to put it briefly.
If you prefer, you can explore the E7018 rods while using AC and DCEP polarity. This is made possible by their high iron powder content rendering them low hydrogen electrodes, hence depositing the metals at a fast rate. Moreover, it does not take long before freezing within E7018 hence creating an unpolluted welding surrounding as opposed to cellulosic electrodes.
When important welds in structural steel are to be welded, the E7018 filler metal is used. These rods are generally referred to as the USA construction industry’s backbone. If you desire a good costly weld, then go for E7018. However, you should ensure that you use them appropriately. Nevertheless, this doesn’t mean that a hobbyist should consider everything. Thus, proper E7018 utilization involves placing them in a particular oven for stick electrodes once the package is opened, but before they are used.
Conclusion
Welding rusty painted metal with E6010 is possible since it has a hydrogen-enhanced strong arc; however, this electrode is not easy for beginners. Moreover, it is always better to clean the metal surface before performing any welding operations. You can set the machine to E6013 for welding thin metals in DCEN mode. Nonetheless, you can go across different metal gauges with this electrode. The E7018 is suitable for a wide range of welding tasks done by enthusiasts and constructors. Even though there are better choices this is not a bad pick if you don’t have anything else otherwise.
